Analytical Balance KERN ABT 320-4NM
Available from stock

The premium model with single-cell weighing system

List price
2.270,00 €

Weighing capacity

320 g

Readability

0,0001 g

Repeatability

0,00015 g

Linearity

± 0,0003 g

Standard
Option
Description
  • Automatic internal adjustment in the case of a change in temperature = 0,5 °C or timecontrolled every 4 h, guarantees high degree of accuracy and makes the balance independent of its location of use
  • Dosage aid: High stability mode and other filter settings can be selected
  • Simple recipe weighing and documenting with a combined tare/print function. In addition, the ingredients for the recipe are numbered automatically and printed out with their corresponding number and nominal weight
  • Identification number: 4 digits, printed on calibration protocol freely programmable
  • Printout of a GLP-compliant calibration report conveniently at the touch of a button
  • Automatic data output to the PC/printer each time the balance is steady
  • Large glass draught shield with 3 sliding doors for easy access to the items being weighed.
  • Protective working cover included with delivery
Specifications

Article codes, product groups & Status information

Model article-code
:
ABT 320-4NM
Model-Serie
:
ABT
Assortment
:
KERN
Product Type
:
Laboratory balances
Product group
:
Analytical balances
Product usage type
:
Main article
EAN code (Model)
:
4045761185562
Successor Model
:
ABP 300-4M
Planned start date
:
2016-2HJ
Customs tariff number
:
90160010
Model Status
:
Discontinued

Technical data - Packing & Shipping

Packaging component - by weight - paper
:
165 g
Packaging component - by weight - cardboard
:
4.805 g
Packaging component - by weight - plastics
:
30 g
Packaging component - by weight - glass
:
0 g
Packaging component - by weight - wood
:
0 g
Packaging component - by weight - foam
:
100 g
Delivery time
:
1 d
Dimensions packaging (W×D×H)
:
405×580×550 mm
Gross weight
:
12 kg
Net weight
:
8 kg
Shipping method
:
Parcel service

Technical data - Primary

Weighing capacity
:
320 g
Readability
:
0,0001 g
Repeatability
:
0,00015 g
Linearity
:
± 0,0003 g

Technical data - Display

Display height
:
14 mm

Technical data - Power supply

Mains adapter/adapter included
:
AUS;CH;EURO;UK;US
Input Voltage
:
220 V - 240 V AC, 50 Hz
Mains adapter
:
Power supply unit

Technical data - Measuring system

Calibration method
:
Internal calibration (automatic);Adjusting with internal weight (manual)
Minimum weight (USP)
:
300 mg
Stabilisation time under laboratory conditions
:
4 s
Tare range
:
320 g
Warm up time
:
8 h
Weighing system
:
Single-Cell
Weighing units
:
Ct;g

Technical data - Counting data

Counting resolution
:
320.000
Mininum piece weight at piece counting (Laboratory)
:
1 mg
Minimum piece weight
:
10 mg

Optional Services

DAkkS Calibration
:
963-101

Technical data - Construction

Dimensions draft shield, inner (W×D×H)
:
200×240×260 mm
Dimensions draft shield, outer (W×D×H)
:
217×356×337 mm
Bubble Level
:
Yes
Material weighing plate
:
Stainless steel
Revolving screw feet
:
Yes
Casing material
:
Metal
Weighing space (W×D×H)
:
168×172×223 mm
Weighing surface (d)
:
80 mm

Technical data - Environmental conditions

Maximum humidity
:
80 %
Maximum operating temperature
:
30 °C
Minimum ambient temperature
:
10 °C
Minimum humidity
:
20 %

Technical data - Verification

Verification approval conforming to 2014/31/EU
:
Yes

Responsible Persons

Product manager
:
Timo Günther

Prices & Discounts

List price
:
2.270,00 €
Warranty
:
36 mon
